PCB Prototype Manufacturing
Kejie provides PCB prototype manufacturing services for engineers, startups and OEMs developing new electronic products. From simple 2-layer boards to complex multilayer, flexible and rigid-flex PCB prototypes, our engineering team supports projects from design review through manufacturing and assembly.
2โ32 Layers โข Flexible PCB โข Rigid-Flex PCB โข PCB Assembly โข Engineering Review
Rigid PCB Prototypes
Prototype manufacturing for standard rigid PCBs, from simple boards to complex multilayer designs.
Flexible PCB Prototypes
Flexible circuit prototypes for compact, lightweight and space-constrained electronic products.
Rigid-Flex PCB Prototypes
Prototype builds for rigid-flex PCB constructions requiring integrated rigid and flexible circuit sections.
PCB Assembly Prototypes
Prototype PCB assembly support including SMT, through-hole, BGA and component sourcing.
Ready to Get Your PCB Prototype Quote?
Upload your Gerber files and choose Prototype under the product stage. Our engineering team will review your design and prepare a PCB prototype quotation.
Typical Prototype Lead Times
Prototype lead times vary depending on layer count, complexity and material requirements. The following lead times represent typical manufacturing schedules.
| PCB Type | Typical Lead Time |
|---|---|
| 2 Layer PCB Prototype | 5โ6 Working Days |
| 4 Layer PCB Prototype | 7โ8 Working Days |
| 6 Layer PCB Prototype | 9โ10 Working Days |
| Flexible PCB Prototype | Upon Review |
| Rigid-Flex PCB Prototype | Upon Review |
| PCB Assembly Prototype | Upon Review |
Prototype Credit Program
Prototype costs can be credited toward a future production order when the project moves from prototype evaluation to volume manufacturing.
1. Build Prototype
Manufacture prototype boards to verify design, quality, materials and production requirements.
2. Evaluate Quality
Test the prototype boards and confirm whether the design is ready for production.
3. Production Credit
When the project moves to volume production, eligible prototype costs can be credited toward the production order.
PCB Prototype Applications
PCB prototypes are commonly used during product development, engineering validation, testing and pre-production verification.
New Product Development
Prototype boards for new electronic products before production release.
Engineering Validation Testing
Design verification and electrical testing during the development cycle.
Proof-of-Concept Prototypes
Prototype hardware used to demonstrate functionality and feasibility.
Industrial Electronics
Prototype boards for new electronic products before production release.
Medical Devices
Design verification and electrical testing during the development cycle.
Telecom
Prototype hardware used to demonstrate functionality and feasibility.
