HDI PCB Manufacturing

What Is an HDI PCB?

A High Density Interconnect (HDI) PCB achieves greater wiring density per unit area than conventional PCBs by using smaller vias, finer trace widths and higher connection pad density. This allows more functionality to be packed into a smaller board footprint โ€” making HDI the preferred choice for smartphones, medical devices, aerospace electronics and any application where size, weight and signal performance matter.

HDI boards are defined by IPC-2226 as boards featuring:

Trace width and spacing โ‰ค 0.10mm (100 ยตm)

Microvia diameter < 0.15mm (150 ยตm)

Capture pad diameter < 0.40mm (400 ยตm)

Connection pad density > 20 pads/cmยฒ

HDI Build-Up Structures We Support

Kejie PCB manufactures HDI boards across all standard build-up configurations:

StructureDescriptionTypical Use
1+N+1One microvia layer each sideEntry-level HDI, mobile devices
2+N+2Two sequential microvia layersMid-range HDI, tablets, IoT
3+N+3Three sequential microvia layersAdvanced HDI, high-performance computing
Any Layer HDIMicrovias on every layerMaximum density, flagship smartphones
Stacked MicroviasMicrovias stacked verticallyFine-pitch BGA, high-speed signal routing
Staggered MicroviasMicrovias offset between layersImproved reliability, easier manufacturing

HDI PCB Manufacturing Capabilities

CapabilitySpecification
Minimum Line Width0.10 mm
Minimum Line Space0.10 mm
Minimum Hole Size0.10 mm
MicroviasSupported
Blind ViasSupported
Buried ViasSupported
CapabilitySpecification
Surface FinishSupported
Fine Pitch ComponentsSupported
BGA RoutingSupported
High Density LayoutsSupported
Prototype ProductionSupported
Volume ProductionSupported

Materials for HDI PCB Manufacturing

HDI boards require materials with tight dimensional stability and low signal loss to perform reliably at high layer counts and fine geometries. Kejie PCB works with:

  • High Tg FR4 โ€” standard choice for most HDI applications, offering improved thermal stability
  • Low Dk/Df FR4 โ€” for signal-sensitive designs requiring reduced dielectric loss
  • Megtron 6 / Megtron 7 โ€” Panasonic materials for high-speed, low-loss HDI applications
  • Isola I-Tera M40 โ€” ultra-low loss laminate for demanding signal integrity requirements
  • Halogen-free options โ€” for RoHS-compliant and environmentally sensitive applications

Our primary material suppliers include Shengyi, EMC, Isola and Panasonic.

What Makes HDI PCB Technology Different?

HDI (High Density Interconnect) PCBs are designed to achieve higher routing density than conventional printed circuit boards. By using microvias, finer traces, smaller pads and advanced layer interconnections, HDI technology allows engineers to reduce board size while increasing functionality and signal performance.

HDI PCB technology is commonly used in compact electronic products where space is limited and component density is high, including mobile devices, communication equipment, medical electronics and advanced industrial systems.

HDI PCB Manufacturing

Major HDI PCB Applications

Smartphones & Mobile Devices

HDI PCBs are widely used in smartphones, tablets and other portable electronic devices where board space is limited.

Industrial Control Systems

Industrial automation and control equipment benefit from HDI technology when high circuit density is required.

Computing & Embedded Systems

HDI PCBs are commonly used in embedded computing platforms, processors and high-performance electronic assemblies.

Why Engineers Choose Kejie as Their HDI PCB Manufacturer

Design Confidentiality โ€” your Gerber files remain private and are permanently deleted after two years of inactivity

Manual CAM review โ€” every HDI project is reviewed by our engineering team before production, catching microvia aspect ratio violations, registration issues and stack-up errors before they reach the floor

Free DFM Review โ€” we review your design for manufacturability at no extra cost, including microvia design rules and blind/buried via feasibility

Sequential lamination expertise โ€” our facility supports multi-lamination cycles required for 2+N+2 and higher build-up structures

Direct engineer access โ€” speak directly with our HDI engineering team throughout your project

HDI vs Standard PCB โ€” When Do You Need HDI?

HDI is the right choice when:

  • Your design includes fine-pitch BGA components with pitch < 0.8mm
  • You need to reduce board size without reducing functionality
  • Your design has signal integrity requirements that standard vias cannot meet
  • Your layer count exceeds what standard through-hole via technology can accommodate efficiently

For designs that don’t require microvia technology, our Rigid PCB manufacturing service supports standard multilayer boards up to 48 layers. For designs combining HDI with flexible sections, see our Rigid-Flex PCB page.

For RF and microwave designs requiring controlled impedance on Rogers materials, see our High Frequency PCB manufacturing page
